Kieselmann type 5080
Applying the Kieselmann Check Valve
The non-return valves of Kieselmann can be used for gas and liquid applications in various industries such as Pharma and food applications. The Kieselmann check valve is available in sizes DN10 to DN100 and OD sizes 1" - 4". They are available in a weld/weld, between flanges and a weld/thread (male part) version according to DIN 11850/DIN 11851.
A check valve, or non return valve, is a valve that prevents the fluid from flowing backwards and ensures that it flows in only one direction. It can be used to prevent the loss of prime of the pump and water hammer. The valve is widely used in water loops.
The type 5083 is a new compact designed check valve. This check valve is mounted between the well known Kieselmann K-Flex flanges.
| Articlenr. | Description | Dimensions | Connection | Elastomer | Stock |
|---|---|---|---|---|---|
|
32638505KI
|
Ball-type non return valve 5080
Buttweld / male DIN11851
DN25 (29) 316 EPDM
|
DN25 (ø 29 mm)
|
Weld / Thread
|
EPDM
|
|
|
32638509KI
|
Ball-type non return valve 5080
Buttweld / male DIN11851
DN40 (41) 316 EPDM
|
DN40 (ø 41 mm)
|
Weld / Thread
|
EPDM
|
|
|
32638511KI
|
Ball-type non return valve 5080
Buttweld / male DIN11851
DN50 (53) 316 EPDM
|
DN50 (ø 53 mm)
|
Weld / Thread
|
EPDM
|
|
|
32638513KI
|
Ball-type non return valve 5080
Buttweld / male DIN11851
DN65 (70) 316 EPDM
|
DN65 (ø 70 mm)
|
Weld / Thread
|
EPDM
|
|
|
33638313KI
|
Ball-type check valve Type 5080
Weld/weld DIN11851 DN65 (70)
1.4404 (316L)
Seal EPDM Ball PTFE
|
DN65 (ø 70 mm)
|
Weld / Weld
|
PTFE / EPDM
|
|
| Articlenr. | Description | Dimension | Elastomer | Stock |
|---|---|---|---|---|
|
32603900KI
|
Non-returnvalve type 5080
Ball DN40 EPDM
|
|
|
|
|
32603898KI
|
Non-returnvalve type 5080
Ball DN25 EPDM
|
|
|
|
|
32603901KI
|
Non-returnvalve type 5080
Ball DN50 EPDM
|
|
|
|
|
32603903KI
|
Non-returnvalve type 5080
Ball DN65 EPDM
|
|
|
|
|
32603905KI
|
Non-returnvalve type 5080
Ball DN80 EPDM
|
|
|
|
Material |
|
| In contact with product | 1.4301 / AISI 304 |
| (Depends on version) | 1.4404 / AISI 316 |
| Seals | EPDM, HNBR, FKM (Viton) |
Technical data |
|
| Sizes |
DN10 – DN100 OD 1" - 4" |
| Connections | Welding DIN 18850 |
|
Male part DIN 11851 Between Flanges |
|
| Max. temp. | 0 - 95°C |
| ID finish | Ra < 0.8 µm |
| Vacuum | 1,5 - 10-6 mbar x L/S (test pressure 0,5mbar) |
| Operating pressure | 10 bar |
