APV Complete FGN1 couplings
Applying the FGN Flange Connection
The APV FGN flange connection is a stress free seal construction which ensures a long seal life. The flange connections are often used in process engineering plants, where proper cleaning and bacteriological safety are necessary. APV flange seals of extremely exact tolerances eliminate leakage and reduce mechanical strain.
The standard elastomer is EPDM, but silicone and Viton are available as options. All sealing materials comply with FDA-requirements. The material is made of AISI 304 or AISI 316 and are also available with 3.1.B certificate. The flange connection is available in the sizes DN25 - DN250 and 1" - 4".
| Articlenr. | Description | Dimensions | Material type | Elastomer | Stock |
|---|---|---|---|---|---|
|
14228961AP
|
Flange connection FGN1
DN50 (53,00 x 1,50) 1.4404 (316L)
HNBR
|
DN50 (ø 53 mm)
|
316 (L)
|
HNBR
|
|
|
14238951AP
|
Flange connection FGN1
DN10 (13,00 x 1,50) 1.4404 (316L)
EPDM
|
DN10 (ø 13 mm)
|
316 (L)
|
EPDM
|
|
|
14238952AP
|
Flange connection FGN1
DN15 (19,00 x 1,50) 1.4404 (316L)
EPDM
|
DN15 (ø 19 mm)
|
316 (L)
|
EPDM
|
|
|
14238953AP
|
Flange connection FGN1
DN20 (23,00 x 1,50) 1.4404 (316L)
EPDM
|
DN20 (ø 23 mm)
|
316 (L)
|
EPDM
|
|
|
14238954AP
|
Flange connection FGN1
1" (25,40 x 1,50) 1.4404 (316L)
EPDM
|
1" (ø 25,4 mm)
|
316 (L)
|
EPDM
|
|
|
14238955AP
|
Flange connection FGN1
DN25 (29,00 x 1,50) 1.4404 (316L)
EPDM
|
DN25 (ø 29 mm)
|
316 (L)
|
EPDM
|
|
|
14238958AP
|
Flange connection FGN1
1,5" (38,10 x 1,50) 1.4404 (316L)
EPDM
|
1,5" (ø 38,1 mm)
|
316 (L)
|
EPDM
|
|
|
14238958APT
|
Flangeconnection complete
FGN1-1.5T execution
1 1/2" EPDM/316L
|
1,5" (ø 38,1 mm)
|
316 (L)
|
EPDM
|
|
|
14238959AP
|
Flange connection FGN1
DN40 (41,00 x 1,50) 1.4404 (316L)
EPDM
|
DN40 (ø 41 mm)
|
316 (L)
|
EPDM
|
|
|
14238959AP3.1
|
Flangeconnection complete
FGN1 execution
DN40 1.4404 (316L) EPDM
Incl. 3.1 cert.
|
DN40 (ø 41 mm)
|
316 (L)
|
EPDM
|
|
|
14238960AP
|
Flange connection FGN1
2" (50,80 x 1,50) 1.4404 (316L)
EPDM
|
2" (ø 50,8 mm)
|
316 (L)
|
EPDM
|
|
|
14238960APT
|
Flangeconnection complete
FGN1-2T execution
2" EPDM/316L
|
2" (ø 50,8 mm)
|
316 (L)
|
EPDM
|
|
