DIN11851 Hose male parts
Male part
DIN 11851 (SC) hoseconnection DIN
DN25 316L
| Articlenr. | Description | Dimensions | Diameter hose liner | Type | Material type | Stock |
|---|---|---|---|---|---|---|
|
14234251
|
Hose male part DIN
DN10 (13,00 x 1,50)
Thread Rd28x1/8"
1.4307 (304L) DIN11851
|
DN10 (ø 13 mm) Rd28x1/8"
|
15 mm
|
Type DIN
|
304 (L)
|
|
|
14234252
|
Hose male part DIN
DN15 (19,00 x 1,50)
Thread Rd34x1/8"
1.4307 (304L) DIN11851
|
DN15 (ø 19 mm) Rd34x1/8"
|
21 mm
|
Type DIN
|
304 (L)
|
|
|
14234253
|
Hose male part DIN
DN20 (23,00 x 1,50)
Thread Rd44x1/6"
1.4307 (304L) DIN11851
|
DN20 (ø 23 mm) Rd44x1/6"
|
27 mm
|
Type DIN
|
304 (L)
|
|
|
14234255
|
Hose male part DIN
DN25 (29,00 x 1,50)
Thread Rd52x1/6"
1.4307 (304L) DIN11851
|
DN25 (ø 29 mm) Rd52x1/6"
|
32 mm
|
Type DIN
|
304 (L)
|
|
|
14234257
|
Hose male part DIN
DN32 (35,00 x 1,50)
Thread Rd58x1/6"
1.4307 (304L) DIN11851
|
DN32 (ø 35 mm) Rd58x1/6"
|
40 mm
|
Type DIN
|
304 (L)
|
|
|
14234259
|
Hose male part DIN
DN40 (41,00 x 1,50)
Thread Rd65x1/6"
1.4307 (304L) DIN11851
|
DN40 (ø 41 mm) Rd65x1/6"
1,5" (ø 38,1 mm) Rd65x1/6"
|
48 mm
|
Type DIN
|
304 (L)
|
|
|
14234261
|
Hose male part DIN
DN50 (53,00 x 1,50)
Thread Rd78x1/6"
1.4307 (304L) DIN11851
|
2" (ø 50,8 mm) Rd78x1/6"
DN50 (ø 53 mm) Rd78x1/6"
|
57 mm
|
Type DIN
|
304 (L)
|
|
|
14234263
|
Hose male part DIN
DN65 (70,00 x 2,00)
Thread Rd95x1/6"
1.4307 (304L) DIN11851
|
DN65 (ø 70 mm) Rd95x1/6"
2,5" (ø 63,5 mm) Rd95x1/6"
|
76 mm
|
Type DIN
|
304 (L)
|
|
|
14234265
|
Hose male part DIN
DN80 (85,00 x 2,00)
Thread Rd110x1/4"
1.4307 (304L) DIN11851
|
DN80 (ø 85 mm) Rd110x1/4"
|
90 mm
|
Type DIN
|
304 (L)
|
|
|
14234267
|
Hose male part DIN
DN100 (104,00 x 2,00)
Thread Rd130x1/4"
1.4307 (304L) DIN11851
|
4" (ø 101,6 mm) Rd130x1/4"
DN100 (ø 104 mm) Rd130x1/4"
|
110 mm
|
Type DIN
|
304 (L)
|
|
|
14234305
|
Hose male part Beer
DN25 (29,00 x 1,50)
Thread Rd52x1/6"
1.4307 (304L) DIN11851
|
DN25 (ø 29 mm) Rd52x1/6"
|
27 mm
|
Type Beer
|
304 (L)
|
|
|
14234307
|
Hose male part Beer
DN32 (35,00 x 1,50)
Thread Rd58x1/6"
1.4307 (304L) DIN11851
|
DN32 (ø 35 mm) Rd58x1/6"
|
34 mm
|
Type Beer
|
304 (L)
|
|
